Strip Foundation is a foundation in the form of a reinforced concrete strip that evenly distributes the load of the building on the soil. It is used for houses, fences, and other structures. To avoid mistakes in construction, an accurate calculation of the strip foundation is necessary. Here comes the strip foundation calculator to the rescue - an online tool that automatically determines the amount of concrete, reinforcement, and other materials.
How to Calculate a Strip Foundation for a House or Fence?
For a strip foundation under a house or a strip foundation under a fence, it is important to consider:
- The depth of the strip foundation (depends on the type of soil and freezing).
- The width of the strip (determined by the load from the structure).
- Reinforcement of the strip foundation (calculation of the amount of reinforcement and its diameter).
The online strip foundation calculator simplifies these calculations: enter the parameters - get the volume of concrete, formwork area, and reinforcement scheme.
Reinforcement for Strip Foundation
Reinforcing the strip foundation strengthens the structure, preventing cracks. To calculate, use the reinforcement calculator for the strip foundation. It takes into account:
- The number of horizontal and vertical bars.
- The spacing between the bars.
- Overlaps during tying.
The optimal diameter of the reinforcement is 10-12 mm. For the construction of a strip foundation under a house, 4-6 bars are usually required in each belt.
Concrete and Formwork Calculation
The concrete calculator for the strip foundation determines the volume of the mixture by the formula:
Length of the strip × Width × Height.
For a foundation 30 m long, 0.4 m wide, and 1 m high, 12 m³ of concrete will be required.
The formwork for the strip foundation is calculated based on the area of the side walls. Note that boards or sheets must withstand the pressure of the concrete.
Conclusion
The strip foundation calculator is an indispensable tool for accurately determining materials: concrete, reinforcement, formwork. It takes into account the depth of laying (depends on the soil and load), the width of the strip, the reinforcement scheme. It automates the calculation of concrete for the foundation and reinforcement. Simply enter the parameters - get a ready plan. Do not rely on guesswork: calculate online!
